Agilent / HP 6632A

Agilent 6632A System DC Power Supply - 100W, 20V, 5A (HP 6632A)

 Output Ratings

• Output voltage: 0 to 20 V
• Output current: 0 to 5 A

Programming Accuracy at 25°C ± 5°C

• Voltage: 10 mV
• + Current: 0.05% + 2 mA

Ripple & Noise (20 Hz to 20 MHz)

• Voltage Normal Mode rms: 0.3 mV
• Voltage Normal Mode peak-to-peak: 3 mV
• Fast mode rms/ peak-to-peak: 1 mV/ 10 mV
• Current rms: 2 mA

The HP/Agilent 6632A is 100 Watt, single output, series pass regulated power suppliy optimized for systems applications. It provides high performance output with a full set of programmable features. Most importantly, the 6632A is one-box solution for system power supply requirements. Both the voltage and current output can be programmed for either CV or CC operation. A built-in DVM and precision current shunt measure (readback) the actual power supply output. The internal HPIB (GPIB) interface allows for complete programmability, including status reporting and interrupt generation with user designated fault conditions. In addition, programming commands (such as VSET for voltage programming) are easy-to-use and selfdocumenting.
